overview
14_ overview
AT A GLANCE (SNB-6003)
Front Side
Item Description
a
Mounting Bracket
Screw Hole
Used to fix the camera on a mounting bracket.
`
The screw size : It is the specification for the screws used to fasten the
camera to the support.
1/4" - 20 UNC
L : 4.5mm±0.2mm (ISO Standard) or 0.197" (ASA
Standard)
b
Auto Iris Lens
(Optional)
Installed on the lens adaptor.
c
Auto Iris Lens
Connector
Used to supply power and output signal to control the iris of the lens.
M
`
Wipe out a dirty surface of the lens softly with a lens tissue or cloth to which you have applied
ethanol.
`
Mounting Bracket is not included.
For more information to use mounting bracket, refer to the product’s documentation.
a
b
c
To Next Page
