setup screen
To Set Exposure (SND-6084)
You can adjust the exposure level of the camera.
1. Select <Exposure>.
2. Select each item and set it properly.
•Brightness : Adjust the screen
brightness.
•Minimum shutter : The limit of the
longest exposure time.
`
Shutter is the mode to set up the range of
the sensor exposure time which will specify
the upper and lower limits for the electronic shutter movement.
`
The framerate may be reduced in the dark condition if Shutter has a lower value than specified in
the Sensor mode.
•Maximum shutter : The limit of the shortest exposure time.
•Anti flicker : It prevents screen flickering incurring from the dissonance between the
surrounding lighting and the frequency.
•SSNR : Select Able or Disable for the video noise elimination function.
•SSNR level : Adjust the noise reduction level.
•Iris : You can set the camera iris to Auto or Manual to your preference.
- Auto : The iris is automatically adjusted to the amount of the surrounding light.
- Manual : Sets the iris F-No to manual.
•Iris F-No : Set up the F value of the iris.
•AGC : Select AGC Control mode.
Adjust the gain value of the video (that, in particular, was recorded at a low
contrast scene and had a lower brightness level than normal) to control the video
brightness.
J
`
The image exposure can be saturated depending on the Shutter setup range.
86_ setup screen
