TOP OF THE UNIT (Fig. 1b)
USB memory device
Connect the USB memory device (such as Digi-
tal voice recorder, etc.) into the USB port.
When a memory device, e.g. a card reader, is
connected to the USB port via long USB cable,
it may interfere to other devices. Please use a
cable shorter than 30 cm.
The USB device in which the USB charge func-
tion is provided enters “Charge” mode when
connected with the unit in the SD mode.
SD/MMC CARD SLOT
Connect the SD/MMC memory device (such as
Digital voice recorder, etc.) into the SD/MMC
port.
CONTROLS
Front panel (Fig.2a)
1. ON Key
• Press to turn the power On/Standby.
2. MEMO/CLK ADJ key
• In the Radio mode: for memory preset.
• In the CD/MP3 mode, USB or SD/MMC for setting
program.
• In the clock mode: for setting of the clock or
timer adjustment.
3. SLEEP/TIMER Key
• To set SLEEP TIME or auto play ON/OFF TIME.
4. FIND/DAS key
5. ALBUM/PRESET UP key
• In the CD/MP3 mode, USB or SD/MMC: selects
next album.
• In the Radio mode: selects the next present station.
6. ALBUM/PRESET DN key
• In the CD/MP3 mode, USB or SD/MMC: selects
previons album.
• In the Radio mode: selects the previons present
station.
7. STOP /BAND Key
• In the CD/MP3 mode, USB or SD/MMC: to stop
play or clear program.
• In the Radio mode: to select the receiving band.
8. SKIP+/UP Key
• In the Radio mode: to receiving frequancy steps up.
• In the CD/MP3 mode, USB or SD/MMC: select a next
trackor search for a passage during play.
• In the REC mode: select Bit rate forward.
9.VOLUME control
• To adjust the volume level.
10. SKIP-/DOWN Key
• In the Radio mode: to receiving frequancy steps
down.
• In the CD/MP3 mode, USB or SD/MMC: to return
to the start of a track, select a previews track or
search for a passage during play.
• In the REC mode: select Bit rate reward.
11. PLAY/PAUSE Key
• In the CD/MP3 mode, USB or SD/MMC: to start or
interrupt play.
12. RANDOM Key
• In the CD/MP3 mode, USB or SD/MMC: to set or
release the random mode.
13. REPEAT key
• In the CD/MP3 mode, USB or SD/MMC: to set or
release the repeat mode.
14. MONO/ST./INTRO key
• CD/MP3 mode, USB or SD/MMC: to set or release
the intro mode.
• Radio mode: to set mono or stereo.
15. SOUND Key
• For selecting Digital Sound Control: FLAT, CLASSIC,
ROCK, POP & JAZZ.
16. FUNCTION Key
• To select the TUNER, CD, USB, CARD or
AUX mode.
17. REMOTE SENSOR
• To receive signals from the remote control.
18. MULTI-DISPLAY
19. PHONE JACK
• Connection for headphones.
20. LINE IN JACK
21. USB socket
22. SD/MMC socket
23. key
• Record sound from CD/MP3/TUNER/AUX
• File copy USB to card or card to usb.
24. INFO/BIT-SEL key
• MP3 mode:appear ID3 Information.
• REC mode:set various Bit rate.
25. MUTE key
• To terminate the sound output.
26. FM ANTENNA
27. AC POWER CORD
28. LINE IN JACK
30. SPEAKER TERMINAL
31. CD TRAY
32. OPEN/CLOSE Key
33. RATING PLATE
34. AM ANTENNA
SUB-WOOFER
1. STANDBY ON/OFF
• To turn the sub-woofer ON/OFF.
2. VOLUME CONTROL
• To adjust the volume level.
3. AUDIO IN
• Connect from main unit.
4. POWER SWITCH
• Press to turn the power ON/OFF.
• It’s not a mains disconnect switch, for
disconnect from the mains, please unplug the
sub-woofer from the socket-outlet.
Warning: Due to the mains switch was located at
the rear panel, the apparatus must be located in
the open area without any obstructions to access
the mains switch.
5. AC POWER CORD
• For sub-woofer only.
29. SUB-WOOFER JACK

Sanyo MAJ-R70 Specifications

Power

power requirement	AC 240V, 50Hz
power consumption	40W
sub-woofer maximum power handling capacity	50W (RMS)

Audio Specifications

cd player speakers impedance	8 ohms
phones impedance	32 ohms
output power	10W X 2(at 8 ohms, 10% distortion)
nominal impedance	8 ohms
reception frequency FM	87.5~108.0MHz
reception frequency AM	522~1, 620KHz (9KHz steps)

Weight and Dimensions

main unit dimensions	170(W) x 272(D) x172(H) mm
main unit weight	2.57 kg
speaker dimensions	155(W) x 194(D) x 210(H) mm
speaker weight	1.5 kg/speaker
sub-woofer dimensions	170(W) x 256(D) x 172(H) mm
sub-woofer weight	3.15 kg
