Sanyo PLV-Z5 User Manual

53
When the input signal is digital from the HDMI terminal, refer to the chart below.
System
mode
RESOLUTION
H-Freq.
(KHz)
V-Freq.
(Hz)
––––––
59.94/60D-VGA
D-480i 720 x 480
––––––
59.94/60
D-575i 720 x 575
––––––
50.00
640 x 480
D-480p 720 x 480
––––––
59.94/60
D-575p 720 x 575
––––––
50.00
System
mode
RESOLUTION
H-Freq.
(KHz)
V-Freq.
(Hz)
D-720p 1280 x 720
––––––
50.00
D-1080i
––––––
59.94/60
––––––
59.94/60D-720p
1920 x 1080
D-1080i 1920 x 1080
––––––
50.00
✔Note:
• You might be able to project images even when signals other than above are inputted, however the functions of the projector could be limited.
1280 x 720
Appendix
System Mode Chart
PLV-Z60 can basically accept the signal from all computers and some video equipment with V- and H-Frequency mentioned
below and less than 100 MHz of Dot Clock.
System mode
H-Freq.
(KHz)
V-Freq.
(Hz)
640 x 480 31.47 59.88
640 x 480 37.86 74.38
640 x 480 37.85 72.81
640 x 480 37.50 75.00
640 x 480 43.269 85.00
640 x 400 37.861 85.08
720 x 400 37.927 85.039
800 x 600 37.88 60.32
800 x 600 46.875 75.00
800 x 600 53.674 85.06
800 x 600 48.08 72.19
800 x 600 37.90 61.03
800 x 600 34.50 55.38
800 x 600 38.60 60.31
800 x 600 47.90 71.92
800 x 600 32.70 51.09
System mode
H-Freq.
(KHz)
V-Freq.
(Hz)
640 x 480 35.00 66.67
1152 x 900 61.85
832 x 624 49.72 74.55
66.00
800 x 600 35.156 56.25
1080i 28.12
50.00
(Interlace)
72.00
1024 x 768 68.677 84.997
48.35 60.00
1024 x 768
1024 x 768
1024 x 768
60.023 75.03
56.47 70.07
60.31 74.92
1024 x 768
1024 x 768
1024 x 768
44.00 54.58
62.04 77.07
61.00 75.70
1024 x 768 63.48 79.35
58.03
1152 x 864 64.20 70.40
1152 x 870
1152 x 900
720p
68.68
75.06
61.20 65.20
45.00
60.00
1024 x 768
46.90 58.20
1024 x 768
1080i 33.75
60.00
(Interlace)
848 x 480
31.020
60.00
1024 x 768
D-1080p
––––––
59.94/601920 x 1080
D-1080p 1920 x 1080
––––––
50.00

Sanyo PLV-Z5 Specifications

General

Number of colors	1.073 billion colors
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Projector native resolution	1280x720
Keystone correction, vertical	± 20 °
Digital zoom	2 x
Zoom capability	Yes
Focal length range	21.3 - 42.6 mm
RS-232 ports	1
Compatibility	WXGA/SXGA/XGA/SVGA/VGA/MAC
Dimensions (WxDxH)	382 x 304.3 x 126.8 mm
Power requirements	100 - 240 V
Horizontal resolution	420 lines
Lamp type	UHP
Lamp power	145 W
Light source type	Lamp
Service life of light source	3000 h
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Display diagonal	0.7 \
Power consumption (typical)	185 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	5000 g
