Schenker MODULAR 150 Installation, Use & Maintenance Manual

4 – MOUNTING AND INSTALLATION COD.150M230.T.2021
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia - ALL RIGHTS RESERVED
23
4.3.3 Fresh water intake for washing
Fresh water
intake for
washing
Tee in downstream of the vessel's fresh water
pressure system.
The following conditions must be respected:
• The flow of the existing fresh water pump
must be min 20 lit/min.
• Flushing must always be performed with
the pressure water system ON.
Min. flow rate must be 20 lit/min.
at 1 bar.
4.3.4 Brine discharge
Salt water
discharge
The salt-water drain shall be ½’’ minimum size
and it has to be preferably above the seawater
level.
Minimum size ½’’
Pre-existing salt
water discharge
(alternatively)
It is possible to use offtakes from existing
apparatuses, provided that:
• It is not the engine cooling water drain or
apparatuses that drain out water with
elevated pressure.
