11. Cleaning and Servicing
Pull the mains plug before any adjustments, main-
tenance or repair.
m Have any work on the device that is not descri-
bed in this instruction guide performed by a pro-
fessional. Only use original parts. Allow the device
to cool off before any maintenance or cleaning is
undertaken. There is a risk of burning!
Always check the device before using it for obvious
defects such as loose, worn or damaged parts, correct
the positioning of screws or other parts. Exchange the
damaged parts.
Cleaning
Do not use any cleaning agents or solvents. Chemical
substances can etch the plastic parts of the device. Ne-
ver clean the device under running water.
• Thoroughly clean the device after every use.
• Clean the ventilation openings and the surface of the
device with a soft brush or cloth.
• Remove chips, dust and dirt with a vacuum cleaner
if necessary.
• Lubricate moving parts regularly.
• Do not allow lubricants to come into contact with swit-
ches, V-belts, pulleys and drill lifting arms.
Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the fol-
lowing parts are therefore also required for use as
consumables.
Wear parts*: Carbon brushes, v-belt, drill
* Not necessarily included in the scope of delivery!
12. Storage
Store the device and its accessories in a dark, dry and
frost-proof place that is inaccessible to children. The
optimum storage temperature is between 5 and 30˚C.
Store the electrical tool in its original packaging.
Cover the electrical tool in order to protect it from dust
and moisture.
Store the operating manual with the electrical tool.
13. Disposal and recycling
The equipment is supplied in packaging to prevent it
from being damaged in transit. The raw materials in this
packaging can be reused or recycled. The equipment
and its accessories are made of various types of mate-
rial, such as metal and plastic. Never place defective
equipment in your household refuse. The equipment
should be taken to a suitable collection center for
proper disposal. If you do not know the whereabouts
of such a collection point, you should ask in your local
council ofces.
10. Electrical connection
The electrical motor installed is connected and ready
for operation. The connection complies with the ap-
plicable VDE and DIN provisions.
The customer‘s mains connection as well as the
extension cable used must also comply with these
regulations.
Important information
In the event of an overloading the motor will switch itself
off. After a cool-down period (time varies) the motor can
be switched back on again.
Damaged electrical connection cable
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Passage points, where connection cables are passed
through windows or doors.
• Kinks where the connection cable has been improperly
fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage regu-
larly. Make sure that the connection cable does not hang
on the power network during the inspection.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with the marking „H05VV-F“.
The printing of the type designation on the connection
cable is mandatory.
AC motor
• The mains voltage must be 230 V~
• Extension cables up to 25 m long must have a cross-
section of 1.5 mm
2
.
Connections and repairs of electrical equipment may
only be carried out by an electrician.
Please provide the following information in the event of
any enquiries:
Type of current for the motor
• Machine data - type plate
• Machine data - type plate
