www.scheppach.com
32
|
GB
7. Before starting the equipment
workbench or solid base. There are two holes for this
purpose in the machine foot.
•
•
•
• When working with wood that has been processed
before, watch out for foreign bodies such as nails
or screws etc.
•
-
• -
8. Attachment
m ATTENTION! Before all maintenance, set-up and
plug.
Assembly tools
1 Open-ended spanner, size 10/13
1 Screwdriver
The saw table and table extension are not assembled
for packaging reasons.
8.1 Assembling the saw table (Fig. 2-3)
• Remove the wing nut (21), the locking handle (22),
the two washers and the clamping plate (23). (Fig. 2)
• Guide the saw table (7) over the Bandsaw blade
(26). Fasten it to the two screws on the machine
frame with the plate (23), the two washers, the wing
nut (21) and the locking handle (22). (Fig. 3)
• Fit the bolt M6x35 (36) with two washers (37) and
the nut (38) to the table. (Fig. 3)
8.2 Fitting the table width enlargement
(Fig. 4 + 4.1 + 4.2 + 4.3 + 4.4)
• Remove the two bolts (39) and washers (40) from
the table width enlargement (8). (Fig. 4)
• Slide the table width enlargement (8) onto the table
(7) mounted on the machine. Ensure that the clamp-
ing lever (10) is open (Fig. 4.1+4.2).
6. Technical data
Electro motor 230 - 240 V ~ 50 Hz
Power
S1* 250W,
S2** 30 min 350W
Revolutions n0 1400 min
-1
Saw band length 1400 mm
Saw band width 3.5 - 12 mm
Saw band width max. 12 mm
Cutting speed 900 m/min
Passage height 0 - 80 mm
Passage width 200 mm
Table size 300 x 300 mm
Table size with min.
extension
380 x 300 mm
Table size with max.
extension
535 x 300 mm
Slewing range of the table 0° - 45°
Max. size of the workpiece 400 x 400 x 80 mm
Overall weight 19 kg
* Operating mode S1, continuous operation
** Operating mode S2, short-term operation with con-
stant load; Duration of nominal operation
The work piece must have a minimum height of 3 mm
and a minimum width of 10 mm.
The total noise values determined in accordance with
EN 61029.
Sound pressure level L
pA
77.4 dB(A)
pA
3 dB
Sound power level L
WA
90.4 dB(A)
WA
3 dB
Wear hearing protection!
vibration emission values (vector sum of three direc-
tions) determined per EN 61029.
