7. Unpacking
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the
packaging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for trans-
port damage. Inform the transport agent imme-
diately of any faults. Later complaints cannot be
considered.
• If possible, store the packaging until the warranty
period has expired.
• Familiarize yourself with the machine with the help
of the operating instructions manual before using it.
• Use only original parts for accessories as well as
consumables and spare parts. Spare parts can be
obtained from your scheppach retailer.
• Please quote our article numbers as well as type
and production year in all your orders.
m ATTENTION
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, lm and small parts! There is a risk of
swallowing and su󰀨ocation!
8. Assembly
m IMPORTANT!
You must fully assemble the appliance before
using it for the rst time!
8.1 Rubber feet (Fig.2)
Secure the four rubber feet (15) to the bottom side of
the equipment using the Allen screws (A) and wash-
ers (B) supplied.
8.2 Planing blade cover (Fig. 3-5)
• First remove the Phillips screw (19) and the fasten-
ing nut (10) on the planer blade cover (9) and the
fastening nut (6) on the swivel arm for planing blade
cover (9a).
• Push the planing blade cover (9) and the swivel arm
(9a) together.
• Retighten fastening nut (10) and Phillips screw (19).
• Fasten the assembly to the holes shown in Fig. 4/
Fig.5 using the fastening nut (6) and the star grip
screw (4)
8.3 Parallel stop (Fig. 6+7)
• Now attach the parallel stop (8) to the machine
housing and fasten it using the Allen screws (C).
8.4 Crank handle for thickness planer chip depth
(Fig. 8)
• The crank handle (12) will be only plugged on the
6. Technical data
Number of knives 2 pieces
Cutter block rpm 9000 1/min
Dimensions 770 x 450 483 mm
Weight 24 kg
Technical data – Surfacing
Max planing width 204 mm
Max chip removal 2,5 mm
Ripping fence l x h 540 x 127 mm
Ripping fence tilting
angle
90°–135°
Surfacing table size 740 x 213 mm
Technical data – Thicknessing
Max planing width 204 mm
Max planing thick-
ness
120 mm
Max chip removal 2 mm
Thicknessing table
size
250 x 270 mm
Drive
Motor V/Hz 230-240V / 50 Hz
Consumption power
P1
1500 W
Subject to technical changes!
Noise
Total noise values determined in accordance with EN
61029.
Sound pressure level L
pA
...........................92 dB(A)
Uncertainty K
pA
..................................................3 dB
Sound power level L
WA
.............................105 dB(A)
Uncertainty K
WA
..................................................3 dB
Wear hearing protection.
The e󰀨ects of noise can cause a loss of hearing
The above-mentioned noise emission values were
measured in accordance with a standardised test pro-
cedure and can be used to compare one power tool
with another.
The above-mentioned noise emission values can also
be used for the preliminary assessment of exposure.
Warning:
• The noise emissions during the actual use of the
power tool may di󰀨er from the above-mentioned
values depending on the power tool being used, in
particular on the type of workpiece being processed.
• Try to keep emissions as low as possible, for ex-
ample by limiting your working time. In this regard,
all the operational cycle phases must be taken into
consideration (such as the times when the tool is
switched o󰀨 or running idle).

Scheppach HMS860 Specifications

General

Power	1500 W
Idle speed	9000 RPM
Product color	Black, Blue, Grey
Dust extraction	Yes
AC input voltage	230 - 240 V
Housing material	-
AC input frequency	50 Hz
Planning width (max)	204 mm

Weight and Dimensions

Depth	805 mm
Width	445 mm
Height	430 mm
Weight	29500 g
Thicknessing table dimensions (W x D)	270 x 251 mm
