- before you refuel.
• Operation of the machine at higher than normal
speed can lead to an increased risk of accidents.
• Take care when carrying out installation work on
the machine, and avoid trapping ngers between
the moving cutting tool and the xed parts of the
machine.
• Please be particularly careful when mowing on
ground that may subside, on nearby landlls,
trenches and embankments.
Residual risks and accident prevention stand-
ards
Neglect of ergonomic principles
Negligent handling of personal protective equip-
ment (PPE)
Negligent handling or ommission of the personal pro-
tective equipment may cause serious injuries.
- Wear prescribed personal protection equipment.
Human behaviour, misbehaviour
- For any work be fully concentrated.
m Residual risks - Cannot be entirely excluded.
Danger from noise
Hearing damage
Prelonged unprotected work with the device may
cause hearing damage.
- Always wear ear-muffs.
In case of emergency
In case of a possibly occuring accident take the nec-
essary rst aid steps as appropriate and obtain quali-
ed medical aid as quickly as possible.
6. Technical data
MS224-53
Technical data
Type engine
four stroke engine/air cooled
Cubic capacity
224 cm³
Rotation speed
2800 U/min
Max. engine output kW
4,0 kW / 5,4 HP
Fuel
Normalbenzin/Bleifrei max.
5% Bioethanol
Capacity tank
1400 cm³
Motor oil
SAE 30 / 10W30
Capacity tank/oil
0,5 l
Cutting height
adjustment
25-75 mm / 7 -stages
Collection bag capacity
70 l
Cutting width
53 cm
Weight
34.7 kg
Subject to technical changes!
Information concerning noise emission measured ac-
cording to relevant standards:
Sound pressure L
pA
= 83,0 dB(A)
Uncertainty K
PA
= 2,5 dB(A)
Sound power L
WA
= 95,52 dB(A)
Uncertainty K
PA
= 0,88 dB(A)
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Vibration A
hv
(left/right) = 4,827 m/s
2
Uncertainty K
PA
= 1,5 m/s
2
Reduce noise generation and vibration to a minimum!
• Use only equipment that is in perfect condition.
• Maintain and clean the equipment regularly.
• Adopt your way of working to the equipment.
• Do not overload the equipment.
• Have the equipment checked if necessary.
• Switch off the equipment when not in use.
• Wear gloves.
When using the petrol lawn mower for extended peri-
ods, vibration-induced circulatory problems may oc-
cur (white nger disease).
We cannot give exact details about the duration of
use in this case because it is different for each indi-
vidual.
The following factors can inuence the condition:
Circulatory problems in the user’s hands
Low outside temperatures
Extended periods of use
We therefore recommend you wear warm work gloves
and take regular breaks.
7. Before rst use
Assembling the components
Some parts of the mower come disassembled. For
quick and easy assembly, read and follow the instruc-
tions below.
Important! You will need the following additional tools
(not supplied) for assembly, and also for maintenance
work:
• A 1 liter measuring jug (oil/petrol resistant)
• A petrol can (5 liters is sufcient for approx. 6 op-
erating hours)
• A funnel (suitable for the tankʼs petrol ller neck)
• Household wipes (to wipe up oil/petrol residue; dis-
pose of these at a lling station)
• A petrol suction pump (plastic, available from DIY
stores)
• An oil can with hand pump (available from DIY
stores)
• 0,6 liter of engine oil (SAE 30)
Assembly
1. Take the mower and attachment parts out of the
packaging and check that all parts are present.
