8. Assembly / Before commissioning
m ATTENTION!
Always make sure the product is fully assembled
before commissioning!
m ATTENTION!
If you intend to use a scarier within the working
area of the robotic mower, the boundary wire (11)
must be buried.
m ATTENTION!
Do not use a strimmer near the boundary wire
(11). Take care when trimming edges near which
the boundary wire (11) is located.
8.1 Setting up / correct position of the charging
station (10)
m ATTENTION
Fix the charging station (10) in place with the
help of a hammer (not in delivery) and the an-
chor pegs (13) only , after you have staked out
the complete working area. (Fig. 16)
m NOTE:
Do not make new holes in the charging station.
m NOTE:
Do not stand with your feet on the charging station
plate.
m ATTENTION
The extension cable as well as the mains cable
must be outside the working area to ensure that
it is not damaged.
• The charging station (10) can be placed near a
shed, a garden shed or the house.
• The charging station (10) must be placed on lev-
el ground.
m NOTE:
Do not place the charging station (10) on a slop-
ing or uneven surface, otherwise it will bend and
the function will be impaired or a defect may occur.
• The charging station (10) must be set up/positioned
such that there is at least one metre of space in
front of the charging station (10), without obstacles
or similar. (Fig. 3)
IP protection classes
Robotic lawnmower IPX5
Charging station IPX4
Power supply IP67
Total weight (net) approx. 7.4 kg
Technical changes reserved!
m IMPORTANT:
This charging unit is suitable exclusively for charging
the product type: RoboCut L500.
Noise & vibration
m Warning: Noise can have serious eects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Device emissions values
Measured sound power level L
WA
50.36 dB
Uncertainty K
WA
4.09 dB
Guaranteed sound power level L
WA
55 dB
Sound pressure level L
pA
44 dB
Uncertainty K
pA
3 dB
The noise emission declaration complies with stand-
ard EN ISO 3744
7. Unpacking
• Open the packaging and carefully remove the prod-
uct.
• Remove the packaging material, as well as the
packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for trans-
port damage. In the event of complaints the carrier
must be informed immediately. Later claims will not
be recognised.
• If possible, keep the packaging until the expiry of
the warranty period.
• Familiarise yourself with the product by means of
the operating manual before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number
as well as type and year of manufacture for your
product.
m ATTENTION!
The device and the packaging material are not
children’s toys! Do not let children play with
plastic bags, lms or small parts! There is a dan-
ger of choking or suocating!
