ST-47 Groundhog - Technical Manual
Diagram Appendix
Page 18.
31412 RevC
ENTRY
SAFE
INTRINSIC
scully
5.87
8.38
6.75
2.25 (57.1)
8.44
R
13.69
10°, 4 PL
G
SEE NOTE 2
2.00
6.62
ENCLOSURE EARTH
2.47
TOP VIEW
5.87
SEE NOTE 2
2. ENTRY HOLES:
1. DIMENSIONS ARE IN INCHES WITH MILLIMETERS
NOTES:
(347.7)
(214.3)
BOTTOM VIEW
FMC APPROVED MODELS: 3/4" NPT
ATEX APPROVED MODELS: M20 X 1.5
IN PARENTHIESS.
BONDING STUD
(168.1)
(50.8)
(149.0)
(62.7)
(12.7)
.50
FRONT VIEW
(212.9)
(149.0)
REAR VIEW
(146.0)
5.75
(171.5)
(MOUNTING LUG CENTERS)
(MOUNTING LUG CENTERS)
6.2 DWG 31412 – Outline Drawing – Control Unit Enclosure
