Scully ST-47 Series User Manual

ST-47 Groundhog - Technical Manual
Diagram Appendix
Page 26.
6.10 DWG 61331 – Internal Wiring Diagram ST-47-EL/D
61331 RevA
1 2 3 4 5 6 7 8 9
1
G
2
N
3
H
4 C
5
NO
120 VAC
INPUT
WET DRY DRY WET
120 VAC
INPUT
GRN
WHT
WHT
BLK
RED
ORN
ST-47-120/240 CIRCUIT MODULE
TB1 (END USER WIRING TERMINAL)
CHASSIS GROUND
GRN
F1 5A FAST BLOW
G
ORN
FRONT COVER
R
WHT
NOTES: UNLESS OTHERWISE SPECIFIED-
1. ``DRY'' CONTACTS CLOSE WHEN ST-47
IS IN PERMISSIVE MODE.
2. PERMISSIVE CONTACT RATED 250 VAC
5 AMP RESISTIVE.
3. USER REPLACEABLE FUSE.
SEE NOTE 3
TB1
TB2
TB3
DEADMAN SWITCH INPUT
NEUT LOADHOT
N.O.
K1
BRN
COMPONENTS
BLK
WHT
BLK
YEL
ORN
BLK
BLK
BLK
CONNECTION TO GROUND BOLT OR GROUND BALL
CONNECT TO LOAD NOT TO EXCEED 135VAC, 5A
JUMPER SEE NOTE 4
4. REMOVE JUMPER WHEN USING EXTERNAL
POWER SOURCE FOR TB1-4. LOAD VOLTAGE RANGE 100-135 VAC.
