Accessories
4.6 Motor operators
3VA molded case circuit breakers
Manual, 04/2015, A5E03603177010-02
263
4.6.1.2
Opening, closing and resetting the 3VA molded case circuit breaker
Opening and closing in MANUAL mode
The plastic window is open, the motor operator is in MANUAL mode. The supply to the LEDs
is also disconnected, but the motor operator remains fully operational.
● Close the 3VA molded case circuit breaker:
Turn the handle clockwise until the switching position indicator displays ON (I).
The molded case circuit breaker is now ON (I). The main contacts are closed.
