Accessories
4.7 Locking and interlocking
3VA molded case circuit breakers
284 Manual, 04/2015, A5E03603177010-02
Interlock combinations
Interlocks can be implemented between the following 3VA molded case circuit breakers:
Possible combinations of handle positions
When a sliding bar with Bowden cable is installed to interlock
two
3VA molded case circuit
breakers, the following combinations of handle position are possible:
When a sliding bar with Bowden cable is installed to interlock
three
3VA molded case circuit
breakers, the following combinations of handle position are possible:
Installation of other accessories
When the front Bowden cable interlock module is fitted, some other accessories cannot be
installed, see chapter Possible combinations of of accessories (Page 142).
