Communication System Manual 3WN1, 3WS1 Circuit-Breakers
Version 1.0 (02/98) Copyright Siemens AG 1998. All rights reserved. 111
Table 19: Diagnostic message
SD LE LEr SD DA SA FC DSA
P
SSA
P
DU.. FCS ED
68H x x 68H 8x 8x x 62/3E 60/3
C
x .. x 16H
Octet Bit no. Description Designation
7 6 5 4 3 2 1 0
1 1
Diagnostic station (slave) does not exist (set by
master)
1
Slave is not ready for data exchange
Diag.station_not_ready
1
Configuration files are not identical
Diag.cfg_Fault
1
Slave has external diagnostic data *
Diag.ext_Fault
1
Requested function not supported in slave.
Diag.not supported
1
Invalid slave response
(sets slave to fixed value = 0)
Diag.invalid_slave_response
1
Incorrect parameterization
(e.g. ID number)
Diag.prm_fault
1
Slave has been parameterized by another master
(set by master)
Diag.master_lock
2 1 1
Slave must be reparameterized.
Diag.Prm_req
1 1
Static diagnostics active
(--> "diagnostic bits" byte)
Diag.Stat_diag
1
Fixed value of 1
1 1
Watchdog is active.
Diag.WD_ON
1 1
Received Freeze command.
Diag.freeze_mode
1 1
Received Sync command.
Diag.sync_mode
x 1
Reserved
1 1
Diagnostics deactivated (set by master)
Diag.deactivated
3 x x x x x x x
Reserved
1
An external diagnostics overflow has occurred.
Diag.ext_overflow
4
Master address after parameterization
Diag.master_add
1 1 1 1 1 1 1 1
without parameterization !
5
ID number: High byte
Ident_1
6
ID number: Low byte
Ident_2
7 0 0 0 0 0 0 1 0
External diagnostics: length of header **
8 0 0 0 0 0 0 0 0
Interface to 3WN1/3WS1 OK
User-specific
0 0 0 0 0 0 0 1
Interface to 3WN1/3WS1 not clear
* The "Diag.ext_fault“ bit (bit 3 in octet 1) is always set in the event of external diagnostics. Octets 7 and 8 are normally only transferred
when this bit is set.
** Octets 7 and 8 are always transferred in the case of the DP/3WN1, 3WS1 interface, even if the "Diag.ext_fault“ bit (bit 3 in octet 1)
has not been set, i.e. if no external diagnostics are active.
Note: Octet 8 is different in interfaces DP/3WN6 and DP/3WN1, 3WS1. See page 60 for details.
4.6 Displaying the data in the 3WN1/3WS1 circuit-breaker
After the interface module has been parameterized and configured by the master, the two stations can start
the data exchange cycle (= normal operating state).
If diagnostic data or faults occur in the interface module, the master is informed about the presence of this
signal by means of a high-priority data message.
