Communication System Manual 3VF Circuit-Breakers
Version 1.0 (05/98) Copyright Siemens AG 1998. All rights reserved.
19
2.1.6 Parameter file
Selection: Assignment: Notes, Codes:
General:
Order number = 3UF5001-3BN00-1 Customer selection
(230 V version here)
Current range = 1.25 - 6.3 A (Customer selection)
Output response = monostable (Customer selection)
Outputs/Inputs = Earth fault (external) Not assigned
Family = Switchgear
DP slave type = SIMOCODE-DP
Designation = 3VF communication
Comment = ' '
PROFIBUS address = 8 Customer selection
Baud rate = 1.5 Mbaud Customer selection
Motor Protection:
Response in event of overload = Warn
Tripping characteristic = CLASS 30
Motor type = Three-phase
Reset = Auto
Blocking threshold = 500 %
Recovery time = 00:00.0
Idle time = 00:00.0
Set current Ie1 = ?? A Rated or setting current for 3VF, to
be defined by customer.
Set current Ie2 = 0.00 A
Upper current limit: DS 130 Par 38
Value = 120 % Default setting (can be changed by
customer)
Response = Warn
Lower current limit: DS 130 Par 39
Value = 80 % Default setting (can be changed by
customer)
Response = Warn
Sensors:
None
Sensor type = No sensor
Short-circuit monitor = No
Response of binary PTC = Shutdown
Analog switch-off threshold = 0 ohm
Analog warning threshold = 0 ohm
Internal ground fault detection = Yes
External ground fault detection = No
Response of ground fault detection = Warn
Motor:
Control function = Overload relay
Run-time = 00:00.0
CS-time = 00:00.0
Locking time = 00:00.0
CSC - Check-back signal closed = Not connected
CSO - Check-back signal open = Not connected
TC - Torque closed = Not connected
TO - Torque open = Not connected
