Communication System Manual 3WN6 Circuit-Breakers
Version 1.0 (05/98)  Copyright Siemens AG 1998. All rights reserved. 71
3.5.3.6 Extract from program listing of supplied example
3.5.3.6.1 DB80
DB80 C:BS3WN6ST.S5D LAE=261 /514
3WN6 ASSIGNMENT TO MESSAGE GROUP 0 Sheet 1
0: KF = +00000;
1: KY = 000,000;
2: KF = +00500; 0:01 TEST UNIT+DELIVERY DATE
3: KY = 001,000;
4: KF = +00500; 0:02 IDENTIFIER NUMBER
5: KY = 002,000;
6: KF = +00500; 0:03 COMMUNICATION TYPE
7: KY = 003,000;
8: KF = +00500; 0:04 RATED CURRENT OF CIRCUIT-BREAKER
9: KY = 004,022;
10: KF = +00500; 0:05 FUNCTION TEST OF RELEASE
11: KY = 005,000;
12: KF = +00000; 0:06
13: KY = 000,000;
14: KF = +00000; 0:07
15: KY = 000,000;
16: KF = +00000; 0:08
17: KY = 000,000;
18: KF = +00000; 0:09
19: KY = 000,000;
20: KF = +00000; 0:10
21: KY = 000,000;
22: KF = +00502; 0:11 CIRCUIT-BREAKER SIZE
23: KY = 001,000;
24: KF = +00502; 0:12 CIRCUIT-BREAKER TYPE
25: KY = 002,000;
26: KF = +00502; 0:13 NO. OF POLES
27: KY = 003,000;
28: KF = +00502; 0:14 VERSION OF RELEASE UNIT
29: KY = 004,000;
30: KF = +00502; 0:15 REVISION LEVEL OF COMMUNICATION
31: KY = 005,000;
32: KF = +00502; 0:16 COMMUNICATION MODULE VERSION
33: KY = 006,000;
34: KF = +00502; 0:17 REVISION LEVEL OF RELEASE UNIT
35: KY = 007,000;
36: KF = +00000; 0:18
37: KY = 000,000;
38: KF = +00000; 0:19
39: KY = 000,000;
40: KF = +00000; 0:20
41: KY = 000,000;
42: KF = +00503; 0:21 COMMUNICATION ADDRESS
43: KY = 001,000;
2*T-Nr. = parameter identifier
2*T-Nr.+1 = parameter subindex
