166/327
Building Technologies Basic Documentation LMV5... CC1P7550en
9 Commissioning instructions for the LMV5 22.05.2018
9 Commissioning instructions for the
LMV5
Practice-oriented setting instructions for the system configuration, the burner
control, and the electronic fuel-air ratio control system
These setting instructions serve for commissioning the LMV5.
To access the parameter setting levels, a password must be entered.
After having entered the correct password, the data appear on the AZL5 (backup for
emergencies). Then, the unit can be parameterized.
After leaving the parameter setting level, we recommend to make a backup.
9.1 Basic configuration
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Updating
BurnerID
Burner identification: E.g. OEM13-10-02-003 (name of OEM = burner manufacturer;
date 13-10-2002, production number 003); minimum 4
characters
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Params & Display
BurnerControl
Configuration
ConfigGeneral
FuelTrainGas
FuelTrainOil
FuelTrainGas from DirectIgniG to Pilot Gp2
FuelTrainOil from LightOilLO to HO w Gasp
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Parameter & Display
BurnerControl
Configuration
ConfigIn/Output
1. Parameterizing the
burner identification
(burner ID)
2. Selecting the fuel
trains
3. Checking the inputs / outputs while taking into account the burner and plant conditions. For details, refer
to chapter Digital inputs.
