SCALANCE XB-200
Operating Instructions, 09/2015, C79000-G8976-C359-03
33
Technical specifications
6
6.1
Technical specifications of the SCALANCE XB208
The following technical specifications apply to the SCALANCE XB208.
Technical specifications
Attachment to Industrial Ethernet
Quantity 8
Connector RJ-45 jack
Properties Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Electrical data
Power supply
Rated voltage
24 VDC
Voltage range 19.2 to 28.8 VDC Safe Extra Low Volt-
age (SELV)
Design
Terminal block, 3 terminals
Cable cross-section
• Minimum
• Maximum
• 0.25 mm
2
(24 AWG)
• 1.5 mm
2
(16 AWG)
Property
Implemented redundantly
Current consumption
at 24 VDC
170 mA
Effective power loss
at 24 VDC
4.1 W
Fusing
F 2.5 A / 125 V
Permitted ambient conditions
Ambient temperature
During operation up to 2000 m
0 ℃ to +60 ℃
During storage
-40 ℃ to +70 ℃
During transportation
-40 ℃ to +70 ℃
Relative humidity
During operation at 25 ℃
≤ 95 % no condensation
Housing, dimensions and weight
Design
compact
Housing material
Polycarbonate (PC-GF10)
Degree of protection
IP20
Dimensions (W x H x D)
40 x 117 x 109 mm
Weight
250 g
Installation options
Installation on a DIN rail
