Technical specifications
6.7 Technical specifications of the SCALANCE XB213-3LD (SC)
SCALANCE XB-200
44 Operating Instructions, 09/2015, C79000-G8976-C359-03
6.7
Technical specifications of the SCALANCE XB213-3LD (SC)
The following technical specifications apply to the SCALANCE XB213-3LD (SC).
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors
Quantity
13
Connector
RJ-45 jack
Properties
Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Optical connectors
Quantity
3
Connector
SC socket
Properties
Full duplex acc. to 100Base-FX
Transmission speed
100 Mbps
Cable type
Single mode glass FO cable
Transmitter output (optical)
• Minimum
• Maximum
• -15 dBm
• -8 dBm
Receiver input
• Sensitivity min.
• Input power max.
• -32 dBm
• -3 dBm
Cable cross-section
• 9/125 μm
Cable length
• 0 to 26 km
Attenuation
• ≤ 0.5 dB/km at 1310 nm
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Electrical data
Power supply
Rated voltage
24 VDC
Voltage range 19.2 to 28.8 VDC Safety Extra Low Voltage
(SELV)
Design
Terminal block, 3 terminals
Cable cross-section
• Minimum
• Maximum
• 0.25 mm
2
(24 AWG)
• 1.5 mm
2
(16 AWG)
Properties Implemented redundantly
Current consumption at 24 VDC 400 mA
*)
Effective power loss
at 24 VDC
9.6 W
Fusing
F 2.5 A / 125 V
