6.5 Technical specifications of the SCALANCE XB216
SCALANCE XB-200
Operating Instructions, 09/2015, C79000-G8976-C359-03
41
6.5
Technical specifications of the SCALANCE XB216
The following technical specifications apply to the SCALANCE XB216.
Technical specifications
Attachment to Industrial Ethernet
Quantity
16
Connector
RJ-45 jack
Properties
Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Electrical data
Power supply
Rated voltage
24 VDC
Voltage range 19.2 to 28.8 VDC Safe Extra Low Volt-
age (SELV)
Design
Terminal block, 3 terminals
Cable cross-section
• Minimum
• Maximum
• 0.25 mm
2
(24 AWG)
• 1.5 mm
2
(16 AWG)
Property
Implemented redundantly
Current consumption
at 24 VDC
280 mA
Effective power loss
at 24 VDC
6.7 W
Fusing
F 2.5 A / 125 V
Permitted ambient conditions
Ambient temperature
During operation up to 2000 m
0 ℃ to +60 ℃
During storage
-40 ℃ to +70 ℃
During transportation
-40 ℃ to +70 ℃
Relative humidity During operation at 25 ℃ ≤ 95 % no condensation
Housing, dimensions and weight
Design
compact
Housing material
Polycarbonate (PC-GF10)
Degree of protection
IP20
Dimensions (W x H x D)
80 x 117 x 109 mm
Weight
400 g
Installation options
Installation on a DIN rail
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40 °C)
> 60 years
