BusAdapter BA 2xLC
7.2 Connecting
BusAdapter
Equipment Manual, 08/2020, A5E41449003-AB
35
7.2 Connecting
Installing the bus connector
Install the PROFINET connector in accordance with the instructions in the PROFINET
Installation Guide (https://www.profibus.com/).
Tools required
3 to 3.5 mm screwdriver, alternatively TX10 (torx).
Accessories required
• If you prepare the FC FO cables with the IE FC FO LC plug, we recommend the FC FO
Termination Kit (LC) (6GK1900-0RL00-0AA0). You can cleave the glass fiber precisely
using the FC FO Termination Kit (LC).
Cleaving the glass fiber
• Wear protective glasses during the cleaving process.
Dispose of the remaining fibers in a suitable waste container.
• Connector for PROFINET fiber-optic cable connection: IE FC FO LC Plug (10 duplex plugs:
6GK1900-1RB00-2AB0)
• Fiber-optic cable:
– IE FC FO Standard Cable GP (62.5/200/230) (6XV1847-2A)
– IE FC FO Trailing Cable (62.5/200/230) (6XV1847-2C)
– IE FC FO Robust Cable (6XV1873-5Rxx)
– IE FC FO Standard Cable (6XV1873-3Axx)
