Parameterizing the Mobile Panel
5.8 General settings
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
111
5.8.6 Storage management
5.8.6.1 Displaying the memory distribution
This function displays the size of the flash memory and its archived data and program data
allocation.
Requirement
The Control Panel is open.
Procedure
1. Open the "System Properties" dialog using the "System" icon.
2. Change to the "Memory" tab.
Cache memory, available and used
If you change the allocation of the memory, malfunctions may occur.
Do not change the memory allocation in the "Memory" tab unless the message "Insufficient
memory" is displayed.
Additional information is available in the information system of the TIA Portal.
5.8.6.2 Setting the project storage location and start delay
There are various storage locations available for storing the compressed source file of your
project, for example, the external memory card or a network drive. This section describes
how to set the location and configure the delay time for the project start.
