Operating a project
8.2 Operating a project on TP 177micro
OP 73micro, TP 177micro (WinCC flexible)
122 Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
Procedure
Set symbolic values with the help of the symbolic screen keyboard.
Proceed as follows:
1. Touch the relevant IO field on the screen.
The symbolic screen keyboard opens and displays the current value.
2. Select an entry from the selection list.
The following options for selecting the entry are available:
– Position the cursor directly on the entry in the selection list by touching the entry.
– Move the cursor to an entry in the selection list using the
, , or
keys.
– Select
to view the infotext of the symbolic IO field.
This button is only enabled if infotext has been configured for the symbolic IO field.
3. Select
to confirm your entries or cancel them with . Both actions close the
screen keyboard.
8.2.3.5 Entering and modifying date and time
Entering the date and time
Enter the date and time in the same way you enter alphanumerical values.
Note
When entering the date and time, please note that the format is determined by the
configured project language.
See also
Entering and editing alphanumerical values (Page 120)
Setting the project language (Page 116)
