3.2.3 Device view of a SCALANCE XC206-2SFP
The following figure shows an overview of the components of the SCALANCE XC206-2SFP.
① Electrical ports ⑦ Power supply
② Pluggable transceiver slots ⑧ Signaling contact
③ Grounding screw ⑨ Serial interface
④ Knurled screw ⑩ "SELECT / SET" button
⑤ Securing bar ⑪ LED display
⑥ Levering aid for moving the securing bar with
a screwdriver
⑫ C-PLUG slot
