Siemens SIMATIC PG User Manual

PC Adapter USB A2
Operating Instructions, 07/2022, C79000-G8976-C293-03
3
Preface
What the consignment contains
The following components are supplied with the PC Adapter USB A2:
• PC Adapter USB A2 (article number: 6GK1571-0BA00-0AA0)
• USB cable (5 m)
• MPI cable (0.3 m)
With the MPI cable, you can connect the PC Adapter USB A2 to MPI networks,
homogeneous PPI networks or to PROFIBUS networks.
Please check that the consignment you have received is complete. If the consignment is
incomplete, contact your supplier or your local Siemens office.
Validity of this documentation
These operating instructions are valid for the following product:
• PC Adapter USB A2 (article number: 6GK1571-0BA00-0AA0)
Note
The PC Adapter USB A2 (article number: 6GK1571
-0BA00-0AA0) replaces the PC Adapter USB
(article number: 6ES7972-0CB20-0XA0).
Content of this documentation
These operating instructions contain information on the commissioning and use of the PC
Adapter USB A2.
Required basic experience
To understand the operating instructions, you require general knowledge of automation
engineering.
You also need to be familiar with using computers or tools similar to PCs (for example
programming devices) with the Microsoft Windows operating system.
Updated operating instructions on the Internet
You will find the current version of these operating instructions on the Product Support pages
under the following entry ID:
68849363 (https://support.industry.siemens.com/cs/ww/en/view/68849363
)

Siemens SIMATIC PG Specifications

General

Brand	Siemens
Model	SIMATIC PG
Category	Adapter
Language	English

Summary

Preface

What the consignment contains

Lists the components supplied with the PC Adapter USB A2 and instructions for checking completeness.

Description of the device

Device Properties and Function

Details on the PC Adapter USB A2's properties, compatibility, and core functionality.

Software requirements

Required Software Packages

Lists the necessary software packages like STEP 7, SIMATIC STEP 7 Professional, and SIMATIC NET for operation.

Hardware installation

Hardware Requirements

Specifies the necessary hardware, primarily a PC with a free USB port.

Connecting the Adapter

Step-by-step guide on connecting the adapter to the PC and the automation system.

Configuration via "Communication Settings" or "Set PG/PC Interface"

Configuration Process

Details the steps to configure the PC Adapter USB A2 using system consoles.

Technical specifications

Technical Specifications Overview

Provides detailed technical data including dimensions, interfaces, EMC, and operating conditions.

Approvals

EMC and RoHS Compliance

Details on Electromagnetic compatibility (EMC) and RoHS directive compliance for the device.

Declarations and Certifications

Covers UK Declaration, cULus, FCC, and C-TICK certifications.
