Preface
The present description is intended as a manual for the machine tool operator
so that he can:
- assess special events when operating the machine correctly
- learn the response of the equipment on special events
- use the provided possibilities to continue work after the special event
- follow the notes referring him to documentation with further information.
This Description includes the alarms that may occur in the following areas: NC
kernel (NCK), cycles and PLC.
Further alarms provided from the MMC area (Man Machine Communication)
can also occur. They are announced to the user in self-explaining alarm lines
on the operator panel. They are not subject of the Diagnostic Instructions. For
special cases in conjunction with the integrated PLC refer to literature on the
SIMATIC S7-300 system.
The alarms are sorted in the Diagnostic Instructions by ascending alarm num-
bers with spaces between them.
Danger
Please check the situation of the equipment carefully using the description of
the particular alarm occurred. Eliminate the causes of occurrence of the alarm
and acknowledge it as specified. Inattention could cause damage to machine,
workpiece, stored settings and - under certain circumstances - to your health.
Table 1_1 Alarm number ranges
000 000 - 009 999 General alarms
010 000 - 019 999 Channel alarms
020 000 - 029 999 Axis/spindle alarms
030 000 - 099 999 Functional alarms
060 000 - 064 999 SIEMENS cycle alarms
065 000 - 069 999 User cycle alarms
070 000 - 079 999 Manufacturer and OEM compile cycles
Scope
Sorting
Safety
NCK alarms
