09.91 1 General Notes
1.1 Product
1 General Notes
1.1 Product
The SINUMERIK 810M is a microprocessor-controlled CNC continuous-path control system for
compact machine tools.
SINUMERIK 810M without integrated machine control panel
((Foto - Nr. einmontieren ))
• The SINUMERIK 810M is used primarily to control boring and milling machines
• Programming can be either computer-aided or manual
• Operation:
– Softkeys for selecting different softkey functions
– 9” graphics screen
– Address/numerical keyboard and function keys
• Screen displays provide information in plain text, e. g. covering:
– current NC operating modes
– setpoint / actual values
– NC and PLC alarms
• Graphics displays aid the programmer when entering programs at the machine.
• ”Blueprint programming” is available for higher-speed programming of complex contour
elements.
• Entered programs may be simulated graphically.
• The SINUMERIK 810M can process 9999 main programs and 9999 subroutines.
200 main programs and subroutines can be stored simultaneously in the memory.
• Lengthy part programs can be executed using the optional “BLOCK TRANSFER” function.
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02 1-1
SINUMERIK 810M, GA3 (BN)
