Siemens SINUMERIK 810M User Manual

01.93 3 Operating Sequences
3.1.13 Program management
Example of a data block
STORE
Program %10
R120 = 30
R121 = 40
. . . . . . . . . . . . INPUT
DISPLAY
current preselected plane
% 10
@ccc ( X:Y:Z )........L
F
INPUT
DISPLAY
STORE
Meaning of the parenthesized expression (X:Y:Z):
The content of the parenthesized expression represents the current plane selection as follows:
X : Y : Z abscissa : ordinate : applicate .
The plane selection must be compatible with the following contour definition. I.e. if the plane
selection has been changed using the function EDIT, back translation of the data block might
not be possible.
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02 3-67
SINUMERIK 810M, GA3 (BN)
