01.93 4 Monitoring Functions
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
3201
"Spindle not synchronous"
Reason:
Remarks:
• Rotary axis operation has been initiated even though the spindle is
not synchronous.
Turn spindle again until it is synchronous.
Alarm No.
Alarm Text:
4100
”No D number active”
Note: Cycles alarm
Alarm No.
Alarm Text:
4101
”Cutter radius=0”
Note: Cycles alarm
Alarm No.
Alarm Text:
4102
”Cutter radius too large”
Note: Cycles alarm
Alarm No.
Alarm Text:
4103
”Tool too wide”
Note: Cycles alarm
Alarm No.
Alarm Text:
4104
”Illegal ZO data block number”
Note: Cycles alarm
Alarm No.
Alarm Text:
4105
”No direction of spindle rotation programmed”
Note: Cycles alarm
Alarm No.
Alarm Text:
6000
to
6063
see explanation
Explanation: These PLC error messages are set by the machine tool manufacturer
(see machine tool manufacturer's documentation)
Alarm No.
6100
to
6163
Explanation: Alarm only on commissioning
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02 4-33
SINUMERIK 810M, GA3 (BN)
