Analog-Units Function Group
20-mA Unit Ether. 7XV5674-0KK00-1AA1
Max. number of connected 20-mA units 4
Max. number of channels per 20-mA unit 12
20-mA Unit Serial 7XV5674-0KK30-1AA1 (RS485) and 7XV5674-0KK40-1AA1 (Fiberglass)
Max. number of connected 20-mA units 4
Max. number of channels per 20-mA unit 12
RTD Unit (Ziehl TR1200) 7XV5662-6AD10
Max. number of connected RTD units 4
Max. number of sensors per RTD unit 12
Sensor type Pt 100 to EN 60751; connection of Ni 100 and Ni 120
sensors possible. The measured values must be
converted in the evaluation unit.
RTD Unit (Ziehl TR1200 IP) 7XV5662-8AD10
Max. number of connected RTD units 4
Max. number of sensors per RTD unit 12
Sensor type Pt 100 to EN 60751; connection of Ni 100 and Ni 120
sensors possible. The measured values must be
converted in the evaluation unit.
Temperature Measured Values
Unit of measurement for temperature
°C or °F, adjustable
Pt 100 -199 °C to 800 °C (-326 °F to 1472 °F)
Ni 100 -54 °C to 278 °C (-65 °F to 532 °F)
Ni 120 -52 °C to 263 °C (-62 °F to 505 °F)
Resolution 1 °C or 1 °F
Tolerance ±0.5 % of the measured value ±1 K
11.34
Technical Data
11.34 Analog-Units Function Group
1198 SIPROTEC 5, High-Voltage Bay Controller, Manual
C53000-G5040-C015-A, Edition 05.2018
