Regent / 500 / 2500 / LT Series
1/2006 21 TP 300-4218-04-RG-SMAN
Figure 41. Air Filter Assembly - Briggs & Stratton
Twin Cylinder Models
A. Knobs
B. Air Filter Cover
C. Air Filter
D. Pre-Cleaner
Air Filter & Pre-Cleaner Service
BRIGGS & STRATTON TWO CYLINDER MODELS
Service Interval: Pre-Cleaner: Every 25 hours or as
required. Air Filter: Every 50 hours or as required.
Replacement Interval: Pre-Cleaner: As required. Air
Filter: Every 200 hours or once per season.
Air Filter Removal & Installation
1. Unscrew the four knobs (A, Figure 41) by turning
counter clockwise.
2. Remove the cover (B). Remove the filter (C) and
pre-cleaner (D).
3. Install the pre-cleaner (D) with the mesh side up.
Install the filter (C) as shown.
4. Install the cover (B) making sure the tabs are inserted
into their slots. Secure by turning screws clockwise
until snug.
B
C
D
A
Change Engine Oil & Filter
KOHLER MODELS
Service Interval: 100 Hours.
Oil Capacity: 1.6 Quarts (1.5L) with oil filter change.
Note: Change engine oil while the engine is warm. Run
the engine for a few minutes, then shut the engine off
and allow it to cool.
1. Clean the area around the dip stick (C, Figure 8) and
oil drain valve (A).
2. Drain engine oil. See OIL DRAIN VALVE
OPERATION above.
3. Remove the oil filter (B, Figure 8). Discard the filter.
4. Turn the new filter upside down and fill with fresh
engine oil. Allow the oil to seep into the new filter for
two minutes.
5. Using a drop of oil on your finger tip, wet the rubber
gasket on the bottom of the new filter.
6. Dump the oil out of the filter and install the filter on
the filter base. Turn the filter clockwise until the
rubber gasket meets the filter base. Then turn 2/3 to
1 full turn more.
7. Fill the crankcase with oil. See CHECK ENGINE OIL
LEVEL.
8. Test run the engine to check for leaks. Stop the
engine for 1 minute, then recheck the oil level.
Figure 40. Recommended Engine Oil - Kohler Models
