I� General Full Size Canister Issues07�03�07
3
B. Check Filter Light
1. General information
The check lter mechanism works on a timer. When the canister has accumulated 25 hours of operating time, the PC board triggers the
check lter light to indicate the HEPA lter should be replaced. Pressing the “Reset” button will reset the timer and turn the light off.
If the light comes on before 25 hours of use, place the hose on a functional test canister or replace the faulty hose and recheck the light� If
the light stays on, verify when the lter was last changed and that the reset button was pressed afterward.
NOTE: Pushing the reset button should reset the timer and turn the light out�
2. The reset switch does not reset the check lter light.
Check the reset switch and wiring to PC connection board as follows:
B� Step 1.
Remove HEPA lter.
B� Step 2.
Remove the covers for the canister power switch and the cord rewind button (be careful not to lose the springs)�
B� Step 3.
1� Remove the 8 (eight) screws holding the black bracket in position, this will allow you to see the wiring� Check the wiring for
broken or pinched wires�
2� If all the wires are good continue to Step 4.
3� If necessary replace any bad wiring�
4� Re-assemble canister and re-test�
B� Step 4.
1� With the hose connected and canister plugged in, take a DC volt meter and check volts at the the PC connection board (red
wires) should read 4 to 5 volts DC�
2� If voltage is good continue to Step 5.
3� If voltage is not good replace the PC board�
4� Re-assemble canister and re-test�
B� Step 5.
Place the tester on the connector located on the reset switch� This should read -4 to -5 volts DC�
2� If voltage is good continue to Step 6.
3� If voltage is not good replace the wiring to the switch�
4� Re-assemble canister and re-test�
B� Step 6.
1� With volt meter reading -4 to -5 volts press the reset switch
and volts should go to zero the return to -4 to -5 volts� If the
voltmeter does not zero out for a moment the reset switch is bad
and should be replaced�
Figure D. HEPA Reset Button Location.
HEPA filter cover
S-Class HEPA filter
Reset Button
2� Re-assemble canister and re-test�
NOTE: You will also want to replace the PC board if the light is coming on
at less than 22 hours of operation�
