9
071807 II. Maintenance Procedures
D. Replacing the LED Light Board
D. Step 1.
Remove the 5 (ve) mounting screws on the underside of the nozzle base tray. (See Figure C. Location of Nozzle Cover
Screws)
D. Step 2.
Remove the 3 (three) screws holding the light board onto the nozzle base tray - the middle screw may have the ground wire
attached.
D. Step 3.
Disconnect the wire connector and replace the light board.
D. Step 4.
Install the 3 (three) screws into LED light board attaching it to the nozzle base tray. NOTE: If the ground wires are on the wiring
harness or the LED light board, place the ground wires under middle screw.
D. Step 5.
Attach the wiring harness connector to the LED light board connector.
D. Step 6.
Reinstall the nozzle cover.
E. Replacing the Spring Assist Assembly
WARNING - If the vacuum is not in upright position injury may occur or vacuum may be damaged.
- Always wear safety glasses during repair.
E. Step 1.
Remove the 5 (ve) mounting screws on the underside of the nozzle base tray. (See Figure C. Location of Nozzle Cover
Screws)
E. Step 2.
With the vacuum locked in the upright position, remove the 2 (two) screws from the bracket holding the spring.
E. Step 3.
Ensure that the spring has been disconnected. Lay the vacuum at to remove the spring mount by pressing the ramped black
tab of the spring mount with a at screwdriver while pulling the spring out-ward.
E. Step 4.
Remove the bracket and mount from the old spring and attach to the new spring.
E. Step 5.
Push the spring mount into the motor cover until the mount snaps into place.
E. Step 6.
Lock the vacuum in the upright position.
E. Step 7.
Insert the two screws in to the spring bracket.
E. Step 8.
Reinstall the nozzle cover.
