| Instruction Manual and Parts List
Oil Reservoir
Installation
3.2
3 erugiF2 erugiF
2
The oil reservoir should rest on the
four corners of the machine table
groove.
Two rubber seats ‘
1’
for supporting
the head portion on the operator
side ‘A’ are fixed on the extended
portion of the table and other two
rubber cushion ‘2’ on the hinge side
‘B’.
Then, the oil reservoir ‘3’ is placed.
Two hinges ‘
1’
fit into the hole in
the machine bed, and the machine
head fitted the table hinge’s rubber
‘
2’
, before the machine head is
placed to the cushions ‘
3’
on the
four corners of the table.
1
Figure 5
Figure 4
Integrated Energy Saving Direct Drive Motor Lockstitch Sewing Machine
