Singer Heavy Duty 4452 User Manual

Connect the machine to a power source as illustrated. (1)
This appliance is equipped with a polarized plug which must be
used with the appropriate polarized outlet. (2)
Unplug power cord when machine is not in use.
The foot control pedal regulates the sewing speed. (3)
Consult a qualified electrician if in doubt as to connect
machine to power source.
Unplug power cord when machine is not in use.
The foot control must be used with the appliance by 4C-316B
(110-120V area) / 4C-326G (230V area) / 4C-316C or 4C-
326C (220-240V area) manufactured by MATSUSHITA
ELECTRIC (TAIWAN) CO., LTD.
Press main switch (A) for power and light on " l ".
For appliance with a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug is
intended to fit in a polarized outlet only one way. If it does not
fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician to install the proper outlet. Do
not modify the plug in any way.
a. Polarized attachment plug
b. Conductor intended to be grounded
Attention:
Foot control
Attention:
Sewing light
IMPORTANT NOTICE
1
2
3
10
Connecting machine to power source
A
GB
a
b

Singer Heavy Duty 4452 Specifications

General

Built-In Stitches	32
Stitch Width	6mm
Stitch Length	4mm
Presser Foot Lifter	Extra high
Drop Feed	Yes
Needle Threader	Automatic
Bobbin Type	Class 15 transparent
Motor	60% stronger motor
Type	Mechanical
Frame	Metal
Presser Feet	All-Purpose Foot, Zipper Foot, Buttonhole Foot, Button Sewing Foot
Warranty	25-year limited
Sewing Speed	1100 stitches per minute
Buttonhole Styles	1-Step
Included Accessories	Needles, Seam Ripper/Lint Brush, Screwdriver, Spool Pin Felt, Auxiliary Spool Pin
Weight	14.6 lbs
Dimensions	15.5 x 6.25 x 12 inches
