Singer Heavy Duty 4452 User Manual

Hold the upper thread with the left hand. Turn the handwheel
(1) towards you (counterclockwise) lowering, then raising
needle.
Gently pull on the upper thread to bring the bobbin thread up
through the needle plate hole (2). Lay both threads to the back
under the presser foot. (3)
1
2
3
30
Raising the bobbin thread
GB

Singer Heavy Duty 4452 Specifications

General

Built-In Stitches	32
Stitch Width	6mm
Stitch Length	4mm
Presser Foot Lifter	Extra high
Drop Feed	Yes
Needle Threader	Automatic
Bobbin Type	Class 15 transparent
Motor	60% stronger motor
Type	Mechanical
Frame	Metal
Presser Feet	All-Purpose Foot, Zipper Foot, Buttonhole Foot, Button Sewing Foot
Warranty	25-year limited
Sewing Speed	1100 stitches per minute
Buttonhole Styles	1-Step
Included Accessories	Needles, Seam Ripper/Lint Brush, Screwdriver, Spool Pin Felt, Auxiliary Spool Pin
Weight	14.6 lbs
Dimensions	15.5 x 6.25 x 12 inches
