Singer Heavy Duty 4452 User Manual

b
a
Raise the presser bar (a). Attach the presser foot holder (b)
as illustrated. (1)
Lower the presser foot holder (b) until the cut-out (c) is directly
above the pin (d). (2)
Raise the lever (e).
Lower the presser foot holder (b) and the presser foot (f) will
engage automatically.
Raise the presser foot. (3)
Raise the lever (e) and the foot disengages.
Attach the seam guide (g) in the slot as illustrated. Adjust
according to need for hems, pleats, etc. (4)
Turn power switch to off ("O") when carrying out any of the
above operations!
Attaching the presser foot
Removing the presser foot
Attaching the seam guide
Attention:
12
34
16
Attaching the presser foot holder
a
c
d
e
f
b
e
g
GB

Singer Heavy Duty 4452 Specifications

General

Built-In Stitches	32
Stitch Width	6mm
Stitch Length	4mm
Presser Foot Lifter	Extra high
Drop Feed	Yes
Needle Threader	Automatic
Bobbin Type	Class 15 transparent
Motor	60% stronger motor
Type	Mechanical
Frame	Metal
Presser Feet	All-Purpose Foot, Zipper Foot, Buttonhole Foot, Button Sewing Foot
Warranty	25-year limited
Sewing Speed	1100 stitches per minute
Buttonhole Styles	1-Step
Included Accessories	Needles, Seam Ripper/Lint Brush, Screwdriver, Spool Pin Felt, Auxiliary Spool Pin
Weight	14.6 lbs
Dimensions	15.5 x 6.25 x 12 inches
