Skytrac CDP-300 Series User Manual

CDP-300 Installation Manual
Document Rev. 01.006 DOC0449 Page 21 of 31
Restricted Proprietary and Confidential Information
Do not connect if DVI-300 is not used
10
RS-232 TX
TX line of RS-232 Databus to DVI-300
Do not connect if DVI-300 is not used
11
Dim Ctl In
Dimmer voltage input
12
Reserved
Reserved for future use - Do not connect
13
Reserved
Reserved for future use - Do not connect
14
Reserved
Reserved for future use - Do not connect
15
Reserved
Reserved for future use - Do not connect
4.2.2 CDP-300 DB-9 CONNECTOR PIN-OUT.
Table 8 – CDP-300 DB-9 Connector Pin Descriptions
PIN #
PIN NAME
FUNCTION/DESCRIPTION
1
N.C
Do not connect
2
RXD
Receive Data
3
TXD
Transmit Data
4
DTR
Data Terminal Ready
5
GND
Ground
6
DSR
Data Set Ready
7
RTS
Ready To Send
8
CTS
Clear To Send
9
N.C
Do not connect
4.3 ISAT-200 SYSTEM INSTALLATION REFERENCE DRAWINGS
Approved installation drawings from the appropriate STC should be used for installation of the ISAT-200 System
of which the CDP-300 is a component.
Please refer to the ISAT-200 System Installation Reference Drawings (DOC0461) when an STC is not applicable.
The document reference is online, please check the correspondence between the online documentation and the printed version.
