SMC Networks ZK2 Series User Manual

-10-
No. ZK2-OM00201
1. How to Order
■Single Unit
Ejector System ZK2 A 12 K 5 A L - 08 - L
Vacuum Pump System ZK2 P 00 K 5 A L - 08 - L
(1) (2) (3) (4) (5) (6) (7) (8)
Remains blank when
no potion is selected.
(1) System/Body Type
(2) Nominal Nozzle Size
(3) Combination of Supply Valve and Release Valve
Note 5, 6)
(4) Rated Voltage
Note 9)
Symbol
Voltage
5
24 VDC
6
12 VDC
0
When (3) is “N”
Note 9) Rated voltage for the supply and release valve
Symbol
System
Body type
Exhaust type
A
Ejector system
Single unit
Silencer exhaust
B
Port exhaust
note 2)
G
High-noise reduction silencer exhaust
C
For manifold
Complex exhaust
note 3)
F
Individual port exhaust
note 2)
H
High-noise reduction silencer exhaust
P
Vacuum pump system
Single unit
Note 1)
-
Q
For manifold
-
Note 1) PS port size of vacuum pump system: mm: ø4, inch: ø5/32”
Note 2) Port size of exhaust port: mm: ø8, inch: ø5/16”
Note 3) The complex exhaust is a combined exhaust method of the common exhaust from the end plate and the direct
exhaust from each station.
Symbol
System
Nominal size
07
Ejector system
Note 4)
ø0.7
10
ø1.0
12
ø1.2
15
ø1.5
00
Vacuum pump system
-
Note 4) Standard supply pressure for nozzle size 07 to 12 is 0.35MPa, 15 is 0.4 MPa.
Symbol
Supply valve
Release valve
K
N.C.
N.C.
J
Note 7)
N.C.
None
R
Self-holding release valve linked
Note 8)
N.C.
N
None
None
Note 5) Solenoid valve with light/surge voltage suppressor
Note 6) Only non-locking type is available for the manual override for “K, J, R”.
Note 7) When “J” is selected for vacuum pump system, install a release valve or vacuum breaker.
Note 8) Supply valve maintains vacuum by energization (20 ms or more). Stopping the vacuum turns on the release valve.
Refer to Self-holding function of supply valve on page 23.
