109
CONTENTS
WELCOME 2
1. SAFETY 3
2. NINA TIMER IO REMOTE CONTROL 5
3. USING NINA TIMER IO 16
Control an item of equipment 16
My function 18
Natural Control function 22
Launch a scenario 27
Sunlight Function 28
Alarm function 32
Timer function 34
Create typical days 39
Program the week 57
View programmed actions 60
4. CUSTOMIZING NINA TIMER IO 68
Customize items of equipment 68
Customize groups 72
Customize scenarios 78
Define timer settings 83
Customize remote control 88
5. ADVANCED SETTINGS 94
6. TROUBLESHOOTING 107
7. ABOUT NINA TIMER IO 108
Copyright © 2017 - 2021 SOMFY ACTIVITÉS SA, Société Anonyme. All rights reserved.
Technical data
Power supply
5 V (DC = Direct Current) via 230 V mains adapter
European compatibility except with Great Britain
Sizes
Remote control: 144.7 X 60.8 X 22.4 mm
Size of remote control base: height = 20 mm, diameter = 87 mm
Size of remote control + base: 144.7 X 87 X 40 mm
Finish
Front face: black
Back face/standard case: Black & Soft touch
Product battery life
Battery life when product not on base:
For information only, not guaranteed: 7 days with 4 manual actions and
20 automatic actions per day for an installation with 15 devices.
A power-saving mode is activated when the product is at 25% charge.
The backlight decreases in order to achieve the 7 days of battery life.
A battery level indicator indicates the battery level.
Radio frequency 868-870 MHz io-homecontrol® Tri-band two-way
Frequency bands and
Maximum power used
868.000 MHz - 868.600 MHz ERP <25 mW
868.700 MHz - 869.200 MHz ERP <25 mW
869.700 MHz - 870.000 MHz ERP <25 mW
Ambient temperature required to
charge the product on its base
Between +5°C and +39°C
Ambient temperature required to
use the product
Between +5°C and +55°C
Storage temperature Between -20°C and +60°C
Weight
Remote control (without base): 117 g with battery
Base: 153 g
Screen backlight Guaranteed 10,000 hours at full intensity
Battery lifetime
300 charging cycles
Warranty: 1 year under normal use
