Sunlight Function
The sunlight function can be activated if there is at
least one sensor in the installation. It is configurable,
and can also be deactivated.
View the sunlight intensity level
1. Select the Groups menu by clicking on the
corresponding icon. Then select the Sun 1 icon.
2. The current sunlight intensity level is displayed.
> The sunlight intensity scale ranges from 0 to
100,000 lux.
Change the threshold and define the scenarios
3. Move the cursor to set a sunlight intensity level =
triggering threshold.
> A default threshold is set.
> The and buttons at the bottom of the
screen can be used to adjust the automatic item
of equipment.
4. Click on the and buttons to define the
scenarios. Then click on OK to confirm.
5. The icons appear around the cursor when the
scenarios have been defined.
> The scenario will be run when the sunlight
intensity level is higher than the threshold. (A)
> The scenario will be run when the sunlight
intensity level is lower than the threshold. (B)
A B
3 4
5
Equipment
Groups
Timer
12:34
1
40,000 lux
Sun 1
ON
OFF
30,000 lux
2
10:27
Sun 1
New group/room
Home
View the sunlight intensity level 28
Change the threshold and define the scenarios 28
Activate/Deactivate the Sunlight function 29
Modify the list of equipment in a "Sensor" group 30
Rename a "Sensor" group 31
