Sony Alpha NEX-5R User Manual

GB
22
Preparing the camera
Attaching/removing the lens
Set the power switch of the camera to OFF before you attach or remove the
lens.
• When attaching a lens, do not press the lens release button.
• Do not use excessive force when attaching a lens.
• The Mount Adaptor (sold separately) is required to use an A-mount lens (sold
separately). For details, refer to the operating manual supplied with the Mount
Adaptor.
• When using a lens equipped with a tripod socket, attach the socket on the lens side
to the tripod to maintain balance.
1
If the cap or the packaging lid
is attached, remove it from the
camera or the lens.
• Quickly change the lens somewhere
away from dusty locations so as to
keep dust or debris from getting
inside the camera.
2
Mount the lens by aligning the
white index marks on the lens
and the camera.
• Hold the camera’s face downward
to prevent the dust from entering
into the camera.
3
While pushing the lens lightly
toward the camera, turn the
lens clockwise until it clicks
into the locked position.
• Be sure to put the lens on straight.
Notes

Sony Alpha NEX-5R Specifications

General

Camera Type	Mirrorless
Sensor Type	APS-C CMOS
Effective Pixels	16.1MP
ISO Sensitivity	ISO 100-25600
Lens Mount	Sony E-mount
Image Processor	BIONZ
LCD Screen Resolution	921, 600 dots
Continuous Shooting	Up to 10 fps
Video Format	AVCHD, MP4
Battery	NP-FW50
Battery Life	Approx. 330 shots
Dimensions	110.8 x 58.8 x 38.9 mm
Autofocus Points	99 phase-detection points, 25 contrast-detection points
Focus Points	99 points (phase detection), 25 points (contrast detection)
Screen Size	3.0 inches
Shutter Speed	1/4000 to 30 sec
Video Resolution	1920 x 1080
Connectivity	Wi-Fi
Storage Media	SD/SDHC/SDXC, Memory Stick Pro Duo
Weight	218 g (body only)
Screen Type	Tiltable LCD
