Sony DCR-HC30 User Manual

5-15
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-HC30/HC30E
LB-095
MS-200
< DIODE >
D302 8-719-074-67 DIODE EDZ-TE61-5.6B
D303 6-500-875-01 DIODE E1S35-AW0C7-01-A3
< RESISTOR >
R302 1-216-841-11 METAL CHIP 47K 5% 1/16W
R303 1-218-971-11 RES-CHIP 33K 5% 1/16W
R304 1-218-975-11 RES-CHIP 68K 5% 1/16W
R305 1-218-989-11 RES-CHIP 1M 5% 1/16W
************************************************************
A-7112-120-A MS-200 BOARD, COMPLETE
***********************
< BATTERY >
0 BT501 1-756-128-11 BATTERY, LITHIUM (SECONDARY)
< CONNECTOR >
CN501 1-691-352-21 CONNECTOR, FFC/FPC (ZIF) 14P
CN502 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
CN503 1-817-913-11 MEMORY STICK DUO CONNECTOR
< DIODE >
D501 6-500-506-01 DIODE TLRMV1021(T15SOY,F)
< RESISTOR >
R501 1-218-941-81 RES-CHIP 100 5% 1/16W
< SWITCH >
S501 1-771-138-82 SWITCH, KEY BOARD (RESET)
< ABSORBER >
VDR501 1-803-974-21 ABSORBER, CHIP SURGE
************************************************************
A-7112-124-A PD-213 BOARD, COMPLETE
**********************
< CAPACITOR >
C602 1-164-939-11 CERAMIC CHIP 0.0022uF 10.00% 50V
C604 1-125-841-91 TANTAL. CHIP 22uF 20.00% 4V
C605 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C606 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C607 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C608 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C610 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C611 1-104-851-11 TANTAL. CHIP 10uF 20.00% 10V
C612 1-164-739-11 CERAMIC CHIP 560PF 5.00% 50V
C614 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V
C615 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V
C616 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V
C617 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C618 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C622 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C623 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C624 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C626 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C627 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C631 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C633 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
< CONNECTOR >
CN601 1-816-179-11 CONNECTOR, FFC/FPC (ZIF) 22P
CN602 1-573-915-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN603 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN605 1-785-905-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN606 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
< DIODE >
D601 8-719-988-61 DIODE 1SS355TE-17
D602 8-719-074-67 DIODE EDZ-TE61-5.6B
< FERRITE BEAD >
FB601 1-414-760-21 FERRITE 0uH
< IC >
IC601 8-759-693-13 IC NJM12904V(TE2)
IC602 8-752-109-72 IC CXM3006R-T4
< COIL >
L601 1-400-588-11 INDUCTOR 0uH
L602 1-400-588-11 INDUCTOR 0uH
L603 1-400-588-11 INDUCTOR 0uH
< TRANSISTOR >
Q601 8-729-427-42 TRANSISTOR XP4211-TXE
Q602 8-729-427-12 TRANSISTOR XP4111-TXE
Q603 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q604 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q605 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q606 8-729-420-24 TRANSISTOR 2SB1218A-QRS-TX
Q607 8-729-420-24 TRANSISTOR 2SB1218A-QRS-TX
Q608 6-550-119-01 TRANSISTOR DTC144EMT2L
Q609 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q610 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
< RESISTOR >
R606 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R607 1-218-989-11 RES-CHIP 1M 5% 1/16W
R608 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R609 1-218-975-11 RES-CHIP 68K 5% 1/16W
R610 1-218-990-11 SHORT CHIP 0
R611 1-218-977-11 RES-CHIP 100K 5% 1/16W
R613 1-220-206-11 METAL CHIP 91K 0.5% 1/16W
R614 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R615 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R616 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
CAUTION :
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
PD-213
The components identified by mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une pièce portant le numéro spécifié.
0 0
Ver 1.2 2004. 07

Sony DCR-HC30 Specifications

General

Digital zoom	120 x
Optical zoom	10 x
Focal length range	2.3 - 23 mm
Total megapixels	0.8 MP
Focus	auto / manual
I/O ports	Audio In/Out, i.LINK (DV) In/Out, S-Video In/Out, USB Terminal, Video In/Out
Power requirements	AC-L25
Display diagonal	2.5 \
Display resolution	123200 pixels
Bundled software	Picture Package
Camera shutter speed	1/4-1/3500 s
Playback zoom (max)	Yes x
Minimum illumination	5 lx
Battery type	NP-FP50
Video formats supported	DV

Weight and Dimensions

Depth	112 mm
Width	50 mm
Height	86 mm
Weight	380 g
