1-4
DCR-HC39E/HC41/HC42/HC42E/HC43/HC43E
ENGLISH JAPANESE
ENGLISH JAPANESE
E
E
E
E
E
Block
Function
61
61
61
62
62
Detailed
Code
00
10
11
00
01
Symptom/State
Difficult to adjust focus
(Cannot initialize focus.)
Zoom operations fault
(Cannot initialize zoom lens.)
Focus lens initializing failure and zoom
lens initializing failure occur simulta-
neously.
Steadyshot function does not work well.
(With pitch angular velocity sensor output
stopped.)
Steadyshot function does not work well.
(With yaw angular velocity sensor output
stopped.)
Self-diagnosis Code
Repaired by:
Correction
Inspect the lens block focus MR sensor (Pin 2, 4 of CN3801 of
VC-378 board) when focusing is performed when the touch panel is
operated in the focus manual mode and the focus motor drive circuit
(IC3803 of VC-378 board) when the focusing is not performed.
Inspect the lens block zoom reset sensor (Pin ws of CN3801 of
VC-378 board) when zooming is performed when the zoom switch
is operated and the zoom motor drive circuit (IC3803 of VC-378
board) when zooming is not performed.
Inspect the flexible board for breakage or loose connection.
If not faulty, inspect the focus and zoom motor drive circuit (IC3803
of VC-378 board).
Inspect pitch angular velocity sensor (SE601 of SI-042 board)
peripheral circuits.
Inspect yaw angular velocity sensor (SE602 of SI-042 board)
peripheral circuits.
