Sony DCR-PC1000 User Manual

DCR-PC1000/PC1000E
• : Uses unleaded solder.
• Refer to page 4-77 for common note for printed wiring board.
4-89 4-90
1-865-895-
>PI<
FP-220
FP-220 FLEXIBLE BOARD
11
1-865-895-
(PANEL REVERSE)
13
45
2
1
6
1
4
3
S001
IC001
LND001
LND002
LND003
LND004
LND005
LND006
FP-236
>PI<
FP-236 FLEXIBLE BOARD
11
1-865-896-
1
6
1
4
CN001
LND001
LND002
LND003
LND004
LND005
LND006
FP-168/FP-220/FP-236
FP-168 FLEXIBLE BOARD
11
39 1
1
1
27
6
1-865-889-
Ver 1.1 2005. 05

Sony DCR-PC1000 Specifications

General

Fader	Wipe, overlap, white, random, monotone, mosaic, black
I/O ports	Audio In Audio Out USB Video In Video Out
Cable type	A/V, USB
Flash memory	16 MB
Horizontal resolution	530 lines
Compatible operating systems	MS Windows XP, MS Windows 2000, MS Windows ME, MS Windows 98 SE, Apple MacOS X 10.1.5 ~
Sensor type	CMOS
Total megapixels	2.8 MP
Optical sensor size	1/6 \
Optical sensor resolution	790.000 pixels
Effective megapixels (movie)	0.67 MP
Display diagonal	2.7 \
Display resolution	123200 pixels
Bundled software	Drivers & Utilities, Sony Picture Package
Camera shutter speed	1/500 - 1/2 s
Built-in microphone	Yes
Battery type	Rechargeable
Operating temperature (T-T)	0 - 40 °C
Camcorder tape type	Mini-DV

Weight and Dimensions

Depth	102 mm
Width	54 mm
Height	117 mm
Weight	400 g
