Sony DCR-PC1000 User Manual

5-17
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-PC1000/PC1000E
A-1099-862-A JK-285 BOARD, COMPLETE
**********************
< CONNECTOR >
CN921 1-815-794-21 CONNECTOR (MULTIPLE)(MULTI CONNECTOR)
CN922 1-816-644-31 FFC/FPC CONNECTOR (LIF) 12P
< DIODE >
D921 6-500-776-01 DIODE MAZW068H0LS0
D922 6-500-776-01 DIODE MAZW068H0LS0
< FERRITE BEAD >
FB921 1-469-667-21 FERRITE, EMI (SMD) (1608)
FB922 1-469-667-21 FERRITE, EMI (SMD) (1608)
FB923 1-469-667-21 FERRITE, EMI (SMD) (1608)
FB924 1-469-667-21 FERRITE, EMI (SMD) (1608)
FB925 1-469-667-21 FERRITE, EMI (SMD) (1608)
FB926 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB927 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB928 1-469-667-21 FERRITE, EMI (SMD) (1608)
FB929 1-469-667-21 FERRITE, EMI (SMD) (1608)
< JACK >
J921 1-793-995-11 JACK, SUPER SMALL TYPE(LANC)
< RESISTOR >
R921 1-216-864-11 SHORT CHIP 0
R922 1-216-864-11 SHORT CHIP 0
R923 1-216-864-11 SHORT CHIP 0
< VARISTOR >
VDR921 1-803-974-21 VARISTOR, CHIP (1608)
VDR922 1-803-974-21 VARISTOR, CHIP (1608)
VDR923 1-803-974-21 VARISTOR, CHIP (1608)
VDR924 1-803-974-21 VARISTOR, CHIP (1608)
************************************************************
A-1099-861-A PD-252 BOARD, COMPLETE
**********************
< CAPACITOR >
C7502 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C7503 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7504 1-165-799-11 TANTAL. CHIP 22uF 20% 4V
C7507 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7509 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7510 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7511 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C7512 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7513 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7514 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7515 1-137-700-11 TANTAL. CHIP 10uF 20% 6.3V
C7516 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7517 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7519 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C7520 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C7521 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7522 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7524 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7525 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7526 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7533 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN7501 1-794-410-11 CONNECTOR, FPC (ZIF) 27P
CN7502 1-816-654-31 FFC/FPC CONNECTOR (LIF) 6P
CN7503 1-794-322-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN7505 1-785-905-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN7506 1-794-322-11 CONNECTOR, FFC/FPC (ZIF) 6P
< DIODE >
D7502 8-719-074-67 DIODE EDZ-TE61-5.6B
< FERRITE BEAD >
FB7501 1-414-760-21 FERRITE, EMI (SMD) (1608)
< IC >
IC7501 8-753-229-95 IC CXM3006CER-T4
< COIL >
L7501 1-400-137-11 INDUCTOR 10uH
L7502 1-400-137-11 INDUCTOR 10uH
L7503 1-400-137-11 INDUCTOR 10uH
L7504 1-400-137-11 INDUCTOR 10uH
< TRANSISTOR >
Q7501 8-729-427-52 TRANSISTOR XP4216
Q7502 8-729-427-23 TRANSISTOR XP4116-TXE
Q7507 6-550-119-01 TRANSISTOR DTC144EMT2L
Q7508 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q7509 8-729-041-23 TRANSISTOR NDS356AP
Q7513 8-729-042-26 TRANSISTOR 2SB1462J-QR (K8).SO
Q7514 8-759-054-48 IC C010-PW2000SV-V110
Q7515 8-759-054-48 IC C010-PW2000SV-V110
Q7516 8-729-037-61 TRANSISTOR UN9113J-(TX).SO
< RESISTOR >
R7501 1-216-864-11 SHORT CHIP 0
R7506 1-218-990-11 SHORT CHIP 0
R7507 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R7508 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R7509 1-218-990-11 SHORT CHIP 0
R7510 1-218-975-11 RES-CHIP 68K 5% 1/16W
R7512 1-218-949-11 RES-CHIP 470 5% 1/16W
R7513 1-218-990-11 SHORT CHIP 0
R7514 1-208-934-11 METAL CHIP 91K 0.5% 1/16W
R7516 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R7523 1-218-969-11 RES-CHIP 22K 5% 1/16W
R7528 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7529 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7530 1-218-978-11 RES-CHIP 120K 5% 1/16W
R7531 1-218-990-11 SHORT CHIP 0
JK-285 PD-252

Sony DCR-PC1000 Specifications

General

Fader	Wipe, overlap, white, random, monotone, mosaic, black
I/O ports	Audio In Audio Out USB Video In Video Out
Cable type	A/V, USB
Flash memory	16 MB
Horizontal resolution	530 lines
Compatible operating systems	MS Windows XP, MS Windows 2000, MS Windows ME, MS Windows 98 SE, Apple MacOS X 10.1.5 ~
Sensor type	CMOS
Total megapixels	2.8 MP
Optical sensor size	1/6 \
Optical sensor resolution	790.000 pixels
Effective megapixels (movie)	0.67 MP
Display diagonal	2.7 \
Display resolution	123200 pixels
Bundled software	Drivers & Utilities, Sony Picture Package
Camera shutter speed	1/500 - 1/2 s
Built-in microphone	Yes
Battery type	Rechargeable
Operating temperature (T-T)	0 - 40 °C
Camcorder tape type	Mini-DV

Weight and Dimensions

Depth	102 mm
Width	54 mm
Height	117 mm
Weight	400 g
