Sony DCR-PC1000 User Manual

Sony EMCS Co.
2005K1600-1
©2005.11
Published by DI Technical Support Department
9-876-872-81
SERVICE MANUAL
SUPPLEMENT-1
File this supplement-1 with the service manual.
(PV05-075)
• Change of repair parts list
Ver 1.3 2005. 11
Page
13 X-2050-257-4 CABINET ASSY, TU (BLACK) (PC1000:J)
13 X-2050-258-3 CABINET ASSY, TU (BLACK)
(PC1000:US,CND,E,KR,JE)
13 X-2050-259-3 CABINET ASSY, TU (BLACK) (PC1000E)
13 X-2050-260-4 CABINET ASSY, TU (SILVER) (PC1000:J)
13 X-2050-261-3 CABINET ASSY, TU (SILVER) (PC1000:E,JE)
13 X-2050-262-3 CABINET ASSY, TU (SILVER)
(PC1000E:JE,E,HK,AUS,CH)
13 X-2050-257-1 CABINET ASSY, TU (BLACK) (PC1000:J)
13 X-2050-258-1 CABINET ASSY, TU (BLACK)
(PC1000:US,CND,E,KR,JE)
13 X-2050-259-1 CABINET ASSY, TU (BLACK) (PC1000E)
13 X-2050-260-1 CABINET ASSY, TU (SILVER) (PC1000:J)
13 X-2050-261-1 CABINET ASSY, TU (SILVER) (PC1000:E,JE)
13 X-2050-262-1 CABINET ASSY, TU (SILVER)
(PC1000E:JE,E,HK,AUS,CH)
Ref. No. Part No. DescriptionRef. No. Part No. Description
5. REPAIR PARTS LIST
5-1. EXPLODED VIEWS
: Changed portion
Before change After change
5-3
5-1-1. OVERALL SECTION
DCR-PC1000/PC1000E
DCR-PC1000
US Model
Canadian Model
Korea Model
Japanese Model
DCR-PC1000E
AEP Model
UK Model
Australian Model
Chinese Model
North European Model
Hong Kong Model
DCR-PC1000/PC1000E
E Model
Tourist Model
LEVEL 2
DCR-PC1000/PC1000E
RMT-831

Sony DCR-PC1000 Specifications

General

Fader	Wipe, overlap, white, random, monotone, mosaic, black
I/O ports	Audio In Audio Out USB Video In Video Out
Cable type	A/V, USB
Flash memory	16 MB
Horizontal resolution	530 lines
Compatible operating systems	MS Windows XP, MS Windows 2000, MS Windows ME, MS Windows 98 SE, Apple MacOS X 10.1.5 ~
Sensor type	CMOS
Total megapixels	2.8 MP
Optical sensor size	1/6 \
Optical sensor resolution	790.000 pixels
Effective megapixels (movie)	0.67 MP
Display diagonal	2.7 \
Display resolution	123200 pixels
Bundled software	Drivers & Utilities, Sony Picture Package
Camera shutter speed	1/500 - 1/2 s
Built-in microphone	Yes
Battery type	Rechargeable
Operating temperature (T-T)	0 - 40 °C
Camcorder tape type	Mini-DV

Weight and Dimensions

Depth	102 mm
Width	54 mm
Height	117 mm
Weight	400 g
