2-7
DSC-F77/FX77
2-10.
LCD MODULE
4
Fle
xible board
(CN702)
5
Fle
xible board
(CN701)
6
LCD module
1
Tw
o scre
ws
(M1.7)
2
Claw
3
2-9.
INNER CABINET (REAR),
KK-29 BO
ARD
4
Inner cabinet
(rear)
5
KK-29 board
2
Flexible board (CN851)
A
Inner cabinet
(rear) block
3
T
wo screws
(DIA. 1.7
×
4)
1
Pressing the lower part of the inner
cabinet (rear) block in the direction of
arrow
A
, disengage the claw with
rotating it in the direction of arrow
B
.
13
15
