2-12
DSC-F77/FX77
1 Tape (K)
4 Remove the FP-585 flexible board block
in the direction of arrow.
3
2 FP-585 flexible board
( CN001)
5 Connector
6 FP-585 flexible board block
Lens section
Lens section
2-15.FP-585 FLEXIBLE BOARD BLOCK
[INSTALLATION OF FP-585 FLEXIBLE BOARD]
3
-
0
7
8
-
1
3
3
B to B connector side
B to B connector side
B to B connector side
Adhesive tape
Adhesive tape
Adhesive tape
Adhesive tape
Lens block side
Lens block side
Lens block side
Lens block side
: Fold mark
Fold
FP-585 flexible board
FP-585 flexible board
1 Fold the FP-585 flexible board.
2 FP sheet
2 FP sheet
-printed side-
B to B connector side
3 Wind the
FP-585 flexible board.
4 FP holder
